Danfoss Filter driers have a solid core with binding material held to an absolute minimum. There are two types of ELIMINATOR® cores. Type DML driers have a core composition of 100% Molecular Sieve, while type DCL contain 80% Molecular Sieve with 20% activated alumina.

Danfoss Filter driers are designed for applications requiring the highest moisture capacity. ELIMINATOR® type DCL driers are designed for applications requiring high moisture capacity and acid adsorption capacity. Available with solder (cu-plated steel connectors) and flare connections.

Features :

The Core type DML

• 100% Molecular Sieve core
• High drying capacity minimizing the risk of acid formation (hydrolysis)
• Recommended for use with HFC and HCFC refrigerants
• Will not deplete oil additives

The Core type DCL

• 80% Molecular Sieve with 20% activated alumina
• Perfect core blend for systems that operate at high condensing temperatures and require high drying capacity
• Recommended for use with HFC and HCFC refrigerants

The Shell

• PED approved for PS 46 bar
• Available with solder (Cu-plated steel connectors) and flare connections
• Corrosion resistant powder-painted finish. Special coating for marine applications available upon request
• Allows installation with any orientation provided the arrow is in the flow direction
• Available in sizes 3 – 75 cubic inches

The Filter

• 25 μm (0.001 in.) filter provides high retention with minimal pressure drop
• Thermally stable up to 120 °C

Model List
