The EK Liquid Line filter drier is a premium compacted bead filter drier with a 20 micron outlet pad for maximum filtration. The EK is a premium universal replacement liquid line filter drier for CFC, HCFC and HFC refrigerants including R-12, R-134a, R-22, R-404A, R-407C, R-410A, R-500, R-502, and R-507.

Features :

• Filtration first for more effective use of surface area of desiccant
• High moisture and acid removal capacity
• Solid copper connections
• Corrosion resistant epoxy powder paint finish
• Approved for POE oils with Copeland compressors
• Shock resistant steel shell construction

Specifications

• • • Desiccant blend – optimized for high water capacity andacid capacity
    • Filtration: 20 microns
    • Maximum working pressure: 680 psig

The Shell

• • • PED approved for PS 46 bar
    • Available with solder (Cu-plated steel connectors) and flare connections
    • Corrosion resistant powder-painted finish. Special coating for marine applications available upon request
    • Allows installation with any orientation provided the arrow is in the flow direction
    • Available in sizes 3 – 75 cubic inches

Model List

Segera hubungi kami untuk info dan pemesanan.

Source : Catalogue
