Descripton
The EK Liquid Line filter drier is a premium compacted bead filter drier with a 20 micron outlet pad for maximum filtration. The EK is a premium universal replacement liquid line filter drier for CFC, HCFC and HFC refrigerants including R-12, R-134a, R-22, R-404A, R-407C, R-410A, R-500, R-502, and R-507.
Features :
- Filtration first for more effective use of surface area of desiccant
- High moisture and acid removal capacity
- Solid copper connections
- Corrosion resistant epoxy powder paint finish
- Approved for POE oils with Copeland compressors
- Shock resistant steel shell construction
Specifications
-
-
- Desiccant blend – optimized for high water capacity andacid capacity
- Filtration: 20 microns
- Maximum working pressure: 680 psig
-
The Shell
-
-
- PED approved for PS 46 bar
- Available with solder (Cu-plated steel connectors) and flare connections
- Corrosion resistant powder-painted finish. Special coating for marine applications available upon request
- Allows installation with any orientation provided the arrow is in the flow direction
- Available in sizes 3 – 75 cubic inches
-
Model List
|
FLARE CONNECTIONS
|
SOLDER CONNECTIONS
|
Segera hubungi kami untuk info dan pemesanan.
Source : Catalogue
Total Review (0)
No Data Found
Specification
- Connection Type Solder (Las)
- Connection Size (Inch) 7/8 Inch
